Z+F AI01 Wire Stripper

January 8, 2020

Z+F AI01 Wire Stripper

The Z+F AI01 wire stripper is a simple and intuitive wire end stripper. Simply enter in the wire size, length of the strip and pull off if required. Very easy to use and gives accurate repeatability with fast results.

This machine comes with blades that can be turned around for double the lifetime on each set of blades, saving consumable costs over time.

Z+F AI01 Wire Stripper

The Z+F AI01 wire stripper is a simple and intuitive wire end stripper. Simply enter in the wire size, length of the strip and pull off if required. Very easy to use and gives accurate repeatability with fast results.

This machine comes with blades that can be turned around for double the lifetime on each set of blades, saving consumable costs over time.

Special features

  • stripping of wire sizes in the range of 0.05 up to 6 mm2 (AWG 30 – 10), continuously adjustable without changing tools
  • variable adjustment of stripping-length and pull-off length between 3 and 20 mm
  • spare blades integrated
  • low weight and compact build

Please contact us for further information or a quote.

Stripping range

0.05 – 6 mm² (AWG 30 – 10)
Stripping length

3 – 20 mm
Pull-off length

3 – 20 mm
Infeed length

22 mm + Stripping length
Cycle time

0.5 s
Power supply

100 – 240/50 – 60/70 V/Hz/VA
Dimensions (W × H × D)

190 x 295 x 190 mm
Weight

7.5 kg
Full stripping
Half stripping
Download
